HDPE Solutions for Every Application

Explore our complete selection of HDPE piping solutions — sourced from trusted manufacturers and delivered with the expertise your project deserves. We ship across US and oversees.

Trusted across industries

Our HDPE piping is trusted across a wide range of applications — delivering strength, flexibility, and long-term reliability in even the most demanding environments.

Oil & Gas

Municipal Water

Mining

Industrial

Agriculture

Telecommunications

Fire Protection

Renewable Energy

Golf Course Irrigation

Why HDPE is the smart choice

HDPE pipe delivers strength, efficiency, and long-term performance — making it the preferred solution for projects of any scale.

Built for Longevity

HDPE delivers decades of reliable performance, resisting corrosion, wear, and environmental stress far better than traditional materials.

Flexible by Design

Its lightweight, flexible construction makes installation easier, faster, and more cost-effective — even in challenging terrain.

Leak-Free Performance

Heat-fused joints create a seamless, leak-proof system, reducing maintenance needs and protecting long-term infrastructure integrity.

Flexible & lightweight
Leak free
Corrosion & chemical resistant
Cost savings in installation
Heat formed joints
Incredibly durable
Exceeds pressure & temperature requirements
Above and below ground capabilities
Get started

HDPE pipe in 1″ to 46″ sizes and beyond

From small-scale installations to large infrastructure builds, our HDPE pipe range meets rigorous performance standards and is engineered to match your project’s exact specifications.

DR 7

Pressure Rating - 355 PSI

DR 9

Pressure Rating - 250 PSI

DR 11

Pressure Rating - 200 PSI

DR 7

Pressure Rating - 355 PSI

Paper Size
Min Wall, in
Avg ID, in
Weight lbs/ft
4"
0.643
3.137
3.40
6"
0.946
4.619
7.37
8"
1.232
6.013
12.50
10"
1.536
7.494
19.42
12"
1.821
8.889
27.31
14"
2.000
9.760
32.93
16"
2.286
11.154
43.01
18"
2.571
12.549
54.43
20"
2.857
13.943
67.20
22"
3.143
15.337
81.32
24"
3.429
16.731
96.77
DR 9

Pressure Rating - 250 PSI

Paper Size
Min Wall, in
Avg ID, in
Weight lbs/ft
4"
0.500
3.440
2.75
6"
0.736
5.065
5.96
8"
0.958
6.594
10.11
10"
1.194
8.219
15.70
12"
1.417
9.746
22.08
14"
1.556
10.701
26.63
16"
1.778
12.231
34.78
18"
2.000
13.760
44.02
20"
2.222
15.289
54.34
22"
2.444
16.819
65.75
24"
2.667
18.346
78.25
DR 11

Pressure Rating - 200 PSI

Paper Size
Min Wall, in
Avg ID, in
Weight lbs/ft
4"
0.409
3.633
2.31
6"
0.602
5.349
5.00
8"
0.784
6.963
8.47
10"
0.977
8.679
13.16
12"
1.159
10.293
18.51
14"
1.273
11.301
22.32
16"
1.455
12.915
29.15
18"
1.636
14.532
36.89
20"
1.818
16.146
45.54
22"
2.000
17.760
55.10
24"
2.182
19.374
65.58
The common dimension and ratio product report is for reference only. It is supplied to help contractors with a standard reference document for weights and sizes of HDPE poly pipe. This document is not a substitute for a licensed professional engineer’s recommendations. For additional questions, please contact Dovetail Distributors.

HDPE pipe in 1″ to 46″ sizes and beyond

From small-scale installations to large infrastructure builds, our HDPE pipe range meets rigorous performance standards and is engineered to match your project’s exact specifications.

Pipe for municipal applications

Ductile iron pipe size (DIPS) and dimension data

All applications & Industries

Iron pipe size (IPS) and dimension data

The common dimension and ratio product report is for reference only. It is supplied to help contractors with a standard reference document for weights and sizes of HDPE poly pipe. This document is not a substitute for a licensed professional engineer’s recommendations. For additional questions, please contact Dovetail Distributors.
